FEATURED 2025  ASV  VT80F  - E001675

MANUFACTURER DESCRIPTION: ASV VT80 FORESTRY PACKAGE TRACKED SKID STEER 2025 -ENGINE: 71.5HP -LIFTING CAPACITY: 2800LBS -CAB: ENCLOSED -HYDRAULICS: HIGH FLOW -OPERATING WEIGHT: 8955LBS -BUCKET SIZE: 72" MANUFACTURER DESCRIPTION: Operations Loader Arms Vertical Operating Weight8,955 lbs Rated Operating Capacity @ 35%2,800 lbs Rated Operating Capacity @ 50%4,000 lbs Ground Pressure3.9 psi Engine Power71.5 hp Shipping Weight8,221 lbs Tipping Load8,000 lbs Travel Speed, Maximum - 1st Speed6.1 mph Travel Speed, Maximum - 2nd Speed9.1 mph Height to Bucket Pin126.5 in. Dump Height at Bucket Discharge92.1 in. Rear Angle of Departure35 degrees Bucket Roll Back at Ground Level20 degrees Ground Clearance13 in. Overall Length with Bucket143 in. Reach at Dump Height32 in. Engine Type Diesel, 4-cylinder, intercooled, turbocharged Mode lYanmar 4TN86CHT Cooling System Belt-driven fan and anti-freeze filled radiator cooling system Intake Air Cleaner Dual-Stage Emission Controls Meets all U.S. EPA Tier 4 final standards Engine Power71.5 hp Gross Horsepower71.5 hp Torque Peak193.8 ft-lb Fuel Tank Capacity21.4 gal Drive Train Track Type General purpose track constructed of rubber compound with embedded co-polymer cords and all-purpose treads. Drive System Two hydrostatic direct drive sprockets controlled by single joystick Track Drive Sprocket Elevated with low-friction, replaceable sprocket rollers Undercarriage Suspension Two independent torsion axles per undercarriage Roller Wheels12 high-density polyurethane and rubber wheels per track. Wheels include sealed bearings Track Width17.7 in. Length of Track on Ground64.5 in. Ground Contact Area2,283 in.2 Front Roller Wheels14 in. Rear and Middle Roller Wheels10 in. Auxiliary Hydraulic Controls Intermittent via joystick button or continuous via console switch Couplers1/2 in. Flat Face Couplers Cooling System High efficiency side-by-side radiator and oil cooler Standard Pump Capacity24.7 gpm Optional High Flow34.3 gpm Maximum System Pressure3,771 psi Electrical System Outlets1 - 12 V inside operator station WiringPre-wired for all factory-available accessories Nominal Charge12 V Battery800 CCA Alternator Charging System80 amp Operator Station SeatVinyl seat with built in operator presence switch, Operator Manual pouch, and 2 in. (51 mm) wide seat belt, adjustable position seat optional ControlsElectronic joystick controls with ISO or H pattern settings, adjustable operator profiles and speeds Engine SpeedHand-operated dial, foot throttle optional Machine DisplayEngine RPM, engine oil pressure, hydraulic oil high temperature, engine coolant temperature, battery voltage, hour meter, fuel level, trip meter, engine diagnostics, system monitoring, fault logging. Deluxe Display Includes7 in. color touch screen, integrated rear view camera, password protection with user profiles, job clock, maintenance schedules ROPSRestraint-ISO 6683, SAE J2292, Cal OSHA 1596, ISO 3471 FOPSMeets ISO 3449: Level I and II (Optional) Illuminaton2 - Fixed forward-facing LED lights 2 - Adjustable rear-facing LED lights 2 - LED side lights (optional) 1 - Interior light Convenience12 V power port Standard FeaturesHorn, backup alarm, cup holder, phone holder, behind seat storage, rear view mirror, lap bar, roof escape hatch, roof panel & rear cab windows. Premium Features: Adjustable joystick & arm rest positions, adjustable directional & air flow HVAC vents, radio with bluetooth & USB, frameless front door, attachment control kit, wiper/washer, beacon switch/outlet, easy-off door
